Technical parameters
| Item | T9(2inch) |
| Printing method | Thermal printing |
| Resolution | 203DPI, 8 dots/mm |
| Paper width | 57.5±0.5mm |
| Printing width | 48mm |
| Interfaces | USB+RS232/TTL; USB+Parallel |
| Paper tore | Manual |
| Command set | ESC/POS compatible commands |
| Print Font | ASCII Font A: 12×24/ASCII Font B: 9×24/Chinese: 24×24 |
| Graphics printing | Support dots printing with different densities, raster bitmap print and downloaded bit image print |
| Code pages | Support Chinese, English, Japanese and other 45 kinds of international character sets |
| UTF-8 | Support |
| Bar codes | UPC-A; UPC-E; EAN-8; EAN13; CODE39; ITF; CODEBAR; CODE128; CODE93; QR CODE |
| External dimension | 85mm×85mm×59.3mm(L×W×H) |
| Opening dimension | 50mm×50mm(L×W) |
| Paper roll diameter | 50mm(Max) |
| TPH life | 50km |
| Power Supply | 12V |
