Tablet Vision Counting & Packaging Machine

Tablet vision counting & packing machine can count tablets, soft gel, pill and other pharmaceuticals for batch package. It is highly accurate by adopting high speed CCD image technology, while counting by weigher is not precise for weight of each tablet is not exactly the same. It solves problem of overlapping of tablets.

Facebook Twitter Pinterest LinkedIn 分享

Description

Automatic tablet vision counting & packaging machine VB82

VB82 Tablet vision counting & packing machine can count tablets, soft gel, pills, and other pharmaceuticals for batch package by adopting high speed CCD image technology. Advantage of vision based bulk counting machine is precise and efficient to save money by eliminating the imprecision of most current weighing solutions and reducing labor force.

Working principle of confectionery vision counter machine:

High speed CCD camera scans objects that fall from vibrating chutes to obtain full projection images through optimized algorithm, machine will count number of falling objects so as to realize the batch package.

Advantage of pharma vision counting machine:

High efficiency: Vision based counter uses large track and scan falling objects , instead of using several narrow tracks to separate objects one by one.
99.99% accuracy for weight of each object is not exactly the same
Insensitive to dust
Fast changeover: One button operation for clearing to change objects
Self-learning software:Easy to calibrate for multiple objects counting
Extremely low maintenance
Reducing labor cost
Compacted design to save space

Technical characteristics and Specification:

High frequency CCD sensor, scanning frequency at 10,000 times per minutes,six million pixels optical lens with minimum recognition size of 0.2mm.
Advanced large capacity FPGA processing and control system, response time at 1 nanosecond.
Optimized algorithm software effectively identifies overlapping objects and micro impurity.
Industrial tablet computer with touch screen makes it easy to store program for different objects.
Intelligent alarming system for abnormal situation and shortage, screen will appear tips.
Patented self-learning technology can achieve to count different objects easily.
One button clearing function.
Connectable to ERP system.
Tailing materials collecting channel is optional.

Notes: production capacity will vary for different particle size and way of packaging.

Model	VB82-1	VB224-2	VC303-2	VF3-223-2
Dimension	Ø1.2-30 mm	Ø2-100 mm	Ø2-100 mm	Ø4-100 mm
Production Capacity	12000 pcs/minute	18000 pcs/minute	18000 pcs/minute	50000 pcs/minute
Vibrating chutes	80+20 mm	220+40 mm	300+30 mm	220+30 mm
CCD camera	scanning frequency at 10,000 times/second
Accuracy	0-1‰ no negative deviation
Power supply	AC 220±10% 50/60 HZ
Power consumption	0.7 KW	0.9 KW	1.5 KW	1.5 KW
Weight	70KG	120KG	225	500
Packing dimension	880600950mm	13006601050mm	13007201450mm	135012701300mm
