Tabs Punching and Trimming Machine For supercapacitor and lithium-ion power battery
SPECIFICATIONS
Functional overview
The machine is suitable for punching and trimming of supercapacitor and lithium-ion power battery' s tabs.
Functional characteristics
1.Adopt hydraulic system as the punching power, with big force and stable speed.
2.Adopt PLC control system to ensure stable and reliable system operation, and simple operation.
3.Rack is welded by high-quality steel forgings, with firm welding and smooth polishing.
4.Equipped with safety light grid and protective door, with safe and reliable device operation.
Technical parameters
|
Punching position precision
|
±0.5mm
|
|
Hole burr
|
＜0.5mm
|
|
Cutting burr
|
＜1mm
|
|
Power Source
|
AC380/50Hz Power:6KW
|
|
Overall dimensions(LxWxH)
|
660x 1100x 1500mm
|
|
Weight
|
420kg
|
