Our li ion battery widely apply to Power Tools, Home Appliances, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts etc.
Key features as follows for your refer
1.Vehicle-grade craft, there are multiple isolation and fixing inside the battery pack, which is conducive to heat dissipation
2. The shell is anti-aging, anti-corrosion, fireproof and waterproof
3. It replaces lead-acid batteries, which is 50% lighter
4. Wide temperature operation
5. Safe and reliable, no explosion
6. Variety of protections, overcharge, overdischarge, overcurrent, over-temperature protection
7. Easy operation, plug and play
8. More than 6000 cycle life
Quick details
1,Modle: 96V 200Ah
2,Shell :Q235 d=3-5mm
3,Build in BMS
4,Warranty: 5Y
|
model
|
QH96V200Ah
|
volt arrange
|
75V-109.5V
|
|
rated volt
|
96V
|
rated capacity
|
200Ah
|
|
discharge current
|
200A
|
discharge temperature
|
-20℃-60℃
|
|
charge current
|
100A
|
charge temperature
|
-0℃-45℃
|
|
size
|
customized
|
weight
|
180kg
|
|
communication
|
CAN，real time monitor
|
service life
|
5Y
|
|
screen
|
EV4.3inch
|
charge/discharge
|
separated
|
More models
|
Project
|
Parameters
|
Notes
|
|
Normal voltage
|
25.6V
|
51.2V
|
83.2V
|
|
|
Voltage arrange
|
20-29.2V
|
40-58.4V
|
65-94.9V
|
|
|
Capacity arrange
|
150-300AH
|
300-600AH
|
300-600AH
|
Customized
|
|
Single electrical core
|
Lithuim iron phosphate(LiFePO4)
|
|
|
Fast charge
|
available
|
Customized
|
|
Charge voltage
|
29.2V
|
58.4V
|
94.9V
|
|
Charge current
|
50-200A
|
|
Continuous discharge current
|
100-400A
|
|
Transient discharge current
|
200-600A
|
|
Work temperature
|
"-20℃-55℃“
|
|
|
Charge hole
|
Anderson/REMA/Charge gun
|
|
|
primary protection
|
Over pressure/Low pressure/Over current/Short-circuit
Over temperature/Low temperature/Relay adhesion test/Wiring falling test
|
|
|
Expanding function
|
Precharge function/Insulative testing
|
Customized
|
|
Showing function
|
Voltage Showing/Liquid screen
|
|
BMS power
|
Out auxiliary power/inner convertor
|
|
Heating function
|
Silicone electric heating
|
|
Shell/Weight
|
Metal plate/Customized
|
|
Communication
|
RS485/CAN
|
FAQ
Q1: what is your MOQ?
A: Only one sample available.
Q2: what is your guarantee life for the battery?
A: 5Y warranty for lifepo4 built in bms battery .
Q3. Can you explain in detail how you match cells for a battery pack before you assembling the pack?
A: We will do the following things before assembling the pack:
a. Select capacity: same capacity rate cells for one pack
b. Measure the voltage: same voltage cells for one pack(difference is under 0.02 v per cell)
c. Measure the inner resistance: same IR cells for one pack (difference is under 1 mOhm)
All above steps are very strict to make sure the pack performance is perfect.
Q4: Before order, can I have samples for testing?
A: Yes, we can provide you samples for testing firstly.
Q5: What kind of environment should lithium batteries store?
A: -40°C~50°C, 65±20%RH storage for a long time(>3 months) and the storage condition shall be:<35°C , 65±20%RH
