Lithium Battery Short Circuit Tester With Temperature Control Function For 0-70℃
SPECIFICATIONS
|
Model
|
Temperature control battery short circuit tester TOB-BSCT-TC
|
|
Warranty
|
One Year limited warranty with lifetime support
|
|
Source voltage
|
AC 220V, 50HZ
|
|
Power
|
3000W
|
|
Short-circuit tester dimension
|
600*800*970mm
|
|
Thermostatic explosion-proof box
|
500*550*500mm
|
|
Weight
|
220kg
|
|
Short-circuit current
|
1000A
|
|
DC response time
|
Less than 5us
|
|
Resistance
|
Less than 5mΩ, customized
|
|
Remote-controlled distance
|
7M No barrier
|
|
Temperature range
|
0-70℃, adjustable
|
|
Temperature fluctuation
|
±1℃
|
|
Temperature error
|
±2℃
|
|
Short-circuit time
|
1-9999s can be set
|
|
Anti explosion case
|
Bottom is provided with four universal wheels, and can move freely
|
