Ti-Sapphire Laser Crystal
Ti:Sapphire(Ti3+:Al2O3) by the advanced growth method of Temperature Gradient Technique (TGT), Ti:Sapphire is an excellent substitute for dye lasers in many applications. It is most widely used crystal for wavelength tunable lasers. It is also an excellent medium capable of generating ultrashort pulse, high gain and high power lasing. Pulsed, quasi-cw, cw, ps and fs lasing with high efficiency.
Ti-Sapphire Crystal SPECIFICATION:
|
Ti2O3 Concetration:
|
0.06-0.48wt%
|
|
Figure of Merit:
|
100 ~ 300
|
|
Diameter:
|
2 ~ 50mm
|
|
Length:
|
2 ~ 130mm
|
|
End Configuration:
|
Flat or Brewst or Specified
|
|
Orientation:
|
Optical axis C normal to rod axis
|
|
a490:
|
1.0~7.5cm-1
|
|
Flatness:
|
<λ/10 at 632.8nm
|
|
Surface Quality:
|
60/40 Scratch/Dig
|
|
Parallelism:
|
<10 arc seconds
|
|
Wavefront Distortion:
|
<λ/4 per inch at 632.8nm
|
|
Coating
|
Upon Requirement
|
