Tile Roof Mount Solar Mounting System
Tile Roof Mounts System designs with great flexibility both for commercial and residential roof solar system.It is suitable for installing framed and frameless modules flushed to the pithed roof. Topbest innovated design hook series products inherenece of good appearance and quality.
Tile Roof Mount Solar Mounting System
Solar Roman Tile Roof Mounting System is good solution for residential and commercial projects and suitable for most flat roof, It accommodated all framed and frameless modules currently on the market. It provide for fast and simple fixing to rafters without affecting the integrity.
☆ Easy Installation
All components are pre-install which help saving labor cost and time.SPC-IK-05
☆ Various Solution
This system is suitable for solar panel installation on the residential or commercial roofs.
☆ Safety and Good Stability
The system designed by skilled engineers can meet the international standards, The main support components should be tested to ensure the strength,stable and safe.
Technical Parameters
| Installation Site: | Tile Roof |
| Material： | Surface Dacrome Q235 |
| Tit Angle: | Flushed with roof,up to 60 deg |
| PV Modules： | Framed, Frameless |
| Module Layourt： | As Designed Portrait and Landscape |
| Wind load： | 60m/s |
| Snow Load： | 1.4KN/m2 |
| Building height： | up to 20m |
| Standards： | AS/NZS 1170& DIN 1055 |
| Warranty： | 10 years warranty |
Components
|
|
|
|
| Tile Roof Hook |
End Clamp Kit |
Mid Clamp Kit | Standard Rail |
Solar Roof Hook Series
|
|
|
|
|
SPC-IK-02 |
SPC-IK-03 | SPC-IK-04 | SPC-IK-05 |
|
|
|
|
|
SPC-IK-06 |
SPC-IK-07 | SPC-IK-08 | SPC-IK-09 |
|
|
|
|
|
SPC-IK-10 |
SPC-IK-11 | SPC-IK-12 | SPC-IK-13 |
|
|
|
|
|
SPC-IK-14 |
SPC-IK-15 |
H-Rail |
H-Rail Splice Kit |
