Top Star TOP-2048MTU-11-2-AS Media Converter 10/100/1000Base-TX 100/1000Base-FX
Features
In accordance with Ethernet standards IEEE802.3, 10/100/1000Base-TX to 1000Base-FX; IEEE802.3, 10/100Base-TX to 100Base-FX
Supported Ports: LC for optical fiber; RJ45 for twisted pair
Auto-adaptation rate and full/half-duplex mode supported at twisted pair port
Auto MDI/MDIX supported without need of cable selection
Up to 6 LEDs for status indication of optical power port and UTP port
External and built-in DC power supplies provided
10/100/1000M Media Converter Up to 1024 MAC addresses supported
10/100/1000M Media Converter with 512 kb data storage integrated, and 802.1X original MAC address authentication supported
10/100M Media converter with 128 K's data buffer RAM
Conflicting frames detection in half-duplex and flow control in full duplex supported
Support LFP function
Applications
For intranet prepared for expansion from 100M to 1000M
For integrated data network for multimedia such as image, voice and etc.
For point-to-point computer data transmission
For computer data transmission network in a wide range of business application
For broadband campus network, cable TV and intelligent FTTB/FTTH data tape
In combination with switchboard or other computer network facilitates for: chain-type, star-type and ring-type network and other computer networks
