Product Details:
- Type:Horizontal multi-joint
- No. of controlled axes: 4
- Arm length: 400mm （225mm + 175mm）
- Working envelope: Axis 1 ±125°
- Axis2 ±145°
- Axis 3 (Z-axis) 0～160mm
- Axis 4 (Z-axis rotation) ±360°
- Maximum*1 speed: Axis 1 660°/s
- Axis2 660°/s
- Axis 3 (Z-axis) 11200mm/s
- Axis 4 (Z-axis rotation) 1500°/s
- Composite: 6.3m/s
- Cycle time (with 2kg load)*2: 0.47s
- Maximum payload mass: 5kg
- Allowable moment of inertia: 0.05kg・m2
- Positioning*3 repeatability X-Y: ±0.01mm
- Z (Axis 3) :±0.015mm
- Axis 4 (Z-axis rotation):±0.007°
- Hand wiring: 8 inputs/8 outputs
- Hand pneumatic joints*4:φ4 ×3 pcs
- Position detection: Absolute
- Robot controller cable:3.5m
- Power capacity: 0.7kVA
- Mass:13kg
Perfect Service
· Order now for immediate delivery via DHL, UPS, Fedex, TNT;
· Payment: 100% T/T on stock items before shipment.
· Warranty: 3 months warranty on new parts;
· Service: 24/7 online service;
· Limited time good prices, free online quotes, huge discounts.
About FAQ
Q1: How long is your delivery time?
A1: If the goods are in stock, it usually takes 2-3 working days. If the quantity is large, it takes 5-7 business days after payment is received.
Q2: What about your shipping package?
A2: Most of our products are shipped in original new packaging and we will cover our professional protective foam packaging ensures damage free shipping worldwide .
