TPS568230RJER TI Switching Voltage Regulators
Parameter
| Manufacturer |
Texas Instruments |
| Product Category |
Switching Voltage Regulators |
| Mounting Style |
SMD/SMT |
| Package / Case |
QFN-20 |
| Number of Outputs |
1 Output |
Series
|
TPS56823
|
Input Voltage - Min
|
4.5 V
|
Input Voltage - Max
|
18 V |
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 125 C
|
Packaging
|
Reel/Cut Tape
|
Factory Pack Quantity
|
3000 |
Introduction
The TPS568230RJER integrates a high-performance synchronous step-down DC-DC converter with two integrated NexFET power MOSFETs to achieve high power density and high efficiency. The device also includes an LDO controller, which provides a low-dropout voltage output for noise-sensitive applications.
Like the TPS568230 RJET, the PMIC features a programmable soft-start function, which allows the output voltage to ramp up gradually during power-up to reduce inrush current and start-up stress on the system. The device also includes overcurrent protection, thermal shutdown, and voltage tracking capabilities, which ensure safe and reliable operation.
The TPS568230RJER is available in a slightly different package, a 3.5mm x 3.5mm VQFN package, and has a wider operating temperature range of -40°C to 125°C. This makes it suitable for use in more rugged and demanding environments.
Application
The TPS568230RJER power management integrated circuit (PMIC) is widely used in various industrial applications, such as industrial automation, robotics, and factory equipment. It is also commonly used in automotive electronics, including infotainment systems, advanced driver assistance systems (ADAS), and powertrain systems. The PMIC's wide operating temperature range and high efficiency make it well-suited for use in harsh environments and demanding conditions. Additionally, the TPS568230RJER is commonly used in telecommunications infrastructure equipment, such as base stations and routers, where high reliability and efficiency are critical. The device's small package size and high power density make it an ideal choice for space-constrained applications in a wide range of industries.
