Triailing edge 220vac triac dimmer switch for dimmable led light

It's a kind of triac dimmer with triailing edge dimming. The dimming operation is touch pannel with three touch botton.


  • CertificationCE, ROHS
  • Dimming modetriac dimming
  • Input Voltage200-240vac

Triailing edge 220vac triac dimmer switch for dimmable led light


It's a triac dimmer which the input voltage is 200vac / 240vac, the frequence can be 50/60Hz. The load is from 25w to 250w. The size is 86*86*38mm(L*W*H).



triailing edge dimmer



  Feature



  • Only connect L(LIVE).
  •  Dimming operation: Touch pannel with three touch botton.
  • Phase-cut model: trailing edge dimming.
  • Memory function: remember the last brightness when turn on
    dimmer again.
  • Over current protection.



 Wiring diagram



triac dimmer switch




  Operation



  • When dimmer under turn off status,Press the Touch key ( ) to turn on the dimmer,and dimmer recover the status(dimming level ) same as last time before it turning off.
  • When dimmer under turn on status, press the Left ( ) Key the brightness down; press the Right ( ) Key,the brightness up; press on the ON/OFF ( ) Key ,dimmer shut down.



  Working principle



  • Working pinciple :Sine wave phase-cut.
  • Control the driver to soft start to achieve continuous,soft dimming.
  • Over-current protection,pretend the driver and dimmer from the damage caused by huge current.
  •  A load fine to set the minimum brightness to prevent the flicker caused by the influence when it is starting.
