About product :
The 9662-810 Terminator Interface Module is a key component designed to interface with the Triconex control system. This module supports hot-spare capability and requires a separate External Termination Panel (ETP) with a cable interface to connect to the Tricon backplane. This setup ensures flexibility and redundancy in the system, enhancing reliability.
The 9662-810 module is mechanically keyed, which prevents incorrect installation in a configured chassis, ensuring proper functionality and preventing errors. The module also comes with a field termination option that can be mounted across a DIN rail, with the dimensions: 4.5 inches (11.43 cm) wide, 5 inches (12.7 cm) in length, and 4.25 inches (10.795 cm) high from the DIN rail.
The main processors in the system execute the control program, which generates outputs that are sent to the output modules, ensuring proper control and communication within the system. This setup enhances system flexibility, simplifies installation, and reduces the risk of faults due to improper configurations.
FAQ:
1.What is the function of the 9662-810 Terminator Interface Module?
The 9662-810 module acts as a termination interface for the Triconex system. It connects digital input modules to the Tricon backplane, providing a reliable and redundant interface for signal transmission. It ensures proper communication between field devices and the control system.
2.What is the role of the External Termination Panel (ETP)?
The External Termination Panel (ETP) provides the necessary interface and cable connections for the 9662-810 module to communicate with the system's backplane. It supports hot-spare functionality, allowing the system to remain operational in the event of a module failure.
3.How does the 9662-810 prevent improper installation?
The 9662-810 is mechanically keyed, which prevents it from being incorrectly installed in a chassis. This design ensures that the module is always installed in the correct orientation, avoiding potential errors in system configuration.
