Twelve-station semi-automatic vacuum liquid injection machines
SPECIFICATIONS
The device performance characteristics:
1. Suitable for supercapacitors, lithium battery electrolyte filling.
2. After the first injection liquid product weighing cycle vacuum, automatic injection stand, pouring weighed,
under acuum state electrolyte can rapidly penetrate into the pole piece, evenly distributed electrolyte,
can effectively improve the super capacitor or battery capacity and internal resistance, internal pressure and cycle life.
3. The device can be placed in the glove box injection fluid, using imported PLC and other accessories English HMI
centralized control, simple operation, easy adjustment, stable performance.
4. You can set the liquid injection speed, vacuum time, put the working gas time, high degree of automation.
5. The high-precision sensor ensures the sensitivity and accuracy of each station operation.
The main technical parameters
|
Configure Power
|
AC220V / 50HZ
|
|
Set the gas source
|
0.4 ~ 0.7MPa
|
|
Battery size
|
φ38 * 130mm（device can be adjusted according to the product specific size）
|
|
Working modes
|
manual discharge, automatic injection
|
|
Prodction capacity
|
4EA / min (depending on the standing time)
|
|
Minimum vacuum degree
|
98KPa
|
|
Equipment size (L * W * H)
|
650 * 600 * 800mm
|
