Applications

 RFID logistics tracking

 Warehouse management

Door control system

 Man management system



Electrical Specifications

Type

JT-629

Frequency

902-928MHZ   865-868MHZ

Gain

4dBi

Beam width

Hor60°  Ver60°

Polarization

Circular

VSWR

≤1.4

F/B Ratio

≥20

Impedance

50Ω

Maximum power

50W

Lightning protection

DC Ground

Connector

N-Female

Mechanical Specifications

Dimension

165*165*20mm

Net weight

0.30kg

Packing size

25*6*19cm

Gross weight

1.35kg

Radome material

ABS

Radome colour

White

Operating temperature

-40-70℃
