Feature:
5dBi antenna
Application:
Radio-frequency reader antenna, used for terminals, parking lots, shopping malls, toll station.
Specification:
|
Item No.
|
JT-613
|
|
Performance
parameters
|
|
|
Working
Frequency
|
902~928 MHz or
865~868MHz
|
|
Antenna gain
|
5dBi
|
|
Polarization
|
Linear
polarization
|
|
VSWR
|
≤1.4
|
|
Beam Width
H-Plane(°)
|
80°
|
|
Beam Width
E-Plane(°)
|
50°
|
|
Impedance(Ω)
|
50
|
|
Connector
|
SMA internal
male screws(accept customized)
|
|
Physical
parameters:
|
|
|
Item size
|
1100x100x30mm
|
|
Package size
|
1150x120x50mm
|
|
Net weight
|
1Kg
|
|
Radome color
|
White
|
|
Radome material
|
PVC
|
|
Working
temperature
|
-40℃~+85℃
|
|
Storage
temperature
|
-45℃~+95℃
|
|
Protection class
|
IP54
|
