Ultrasonic Homogenizer through its “cavitation effect” achieve oil blended with water emulsification, water blended with oil emulsification, dispersion phase and continuous phase mixing homogenization, it’s an advanced phonochemistry method to replace the traditional emulsify process such as propeller and colloid mill,etc. An important feature of ultrasonic emulsify is that you don’t need use or use little emulgator to get most stable emulsion.
OLLITAL brand ultrasonic series products all use ultrasonic “cavitation effect” to disperse the glomerate particles. Add particle suspension liquid (liquid phase) in super strong sound field, use suitable ultrasonic amplitude to process.
Food industry, paper making, oil paint, chemical industry,pharmaceutical, spinning, fuel oil thermoelectricity, fuel oil central air-conditioning, oil, metallurgy, etc. Fuel oil blended with water combustion is an important arisen program now.
|
Model
|
OLT-UI-50
|
OLT-UI-51
|
OLT-UI-52
|
|
Frequency (KHz)
|
20-30KHz
Automatic tracking
|
20-25KHz
Automatic
tracking
|
19.5-20.5KHz
Automatic
tracking
|
|
Power
(W)
|
5-500W
adjustable
|
10-1000W
adjustable
|
20-1500W
adjustable
|
|
Horn
(mm)
|
Φ6
|
Φ10
|
Φ20 or 22
|
|
Optional
Horn
(mm)
|
Φ2、Φ3、Φ8、Φ10
|
Φ6、Φ8、Φ10、Φ12、Φ15
|
Φ10、Φ15、
Φ25
|
|
Crush capacity
(ml)
|
0.2-400
|
10-600
|
50-1500
|
|
Instrument protection function
|
Over-
temperature protection
|
Over-
temperature
protection
|
Over-
temperature
protection
|
|
Display
|
4.3 inch TFT
|
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
