Universal Laptop Battery Tester 15V3A With 8 Channels
SPECIFICATIONS
|
Source Voltage
|
AC 220V ±10% / 50Hz Or Customized to 110V
|
|
Resolution
|
AD：16bit；DA：12bit
|
|
Input impedance
|
≥1MΩ
|
|
Input power
|
>360W
|
|
Channel characteristic
|
Constant current source with constant voltage source with double closed-loop structure
|
|
Channel control mode
|
Independent control
|
|
Voltage
|
Measure range/channel
|
Charge：30mV~15V；Discharge ：2V~15V
|
|
Min discharge voltage
|
2.0V
|
|
Precision
|
± 0.1% of FS
|
|
Stability
|
± 0.1% of FS
|
|
Current
|
Measure range/channel
|
Charge ：6mA~3A；Discharge ：6mA~3A
|
|
Precision
|
± 0.1% of FS
|
|
Stability
|
± 0.1% of FS
|
|
Power
|
Unit channel power
|
45W
|
|
Stability
|
± 0.2% of FS
|
|
Time
|
Current response time
|
Current（10%~90%）: 20ms
|
|
Time setting
|
≤(365*24)hour /step mode (00：00：00（h、min、s）
|
|
Date record
|
Record condition
|
Time △T：（1s ~60000s）
|
|
Voltage △U：（30mV~15V）
|
|
Current △I：（6mA~3A）
|
|
Charging
|
Charging mode
|
Constant Current Charge、Constant Voltage Charge、
Constant Current and Constant Voltage Charge
|
|
End Condition
|
Voltage、Current、Relative Time、Capacity、-ΔV
|
|
Discharging
|
Discharging mode
|
Constant Current Discharge, Constant Power Discharging
|
|
End Condition
|
Voltage、Current、Relative Time、Capacity、-ΔV
|
|
Cycle
|
Range
|
1~65535
|
|
Step for single cycle
|
254
|
|
Nested Loop
|
Nested loop Function，Max Support 3 Layers
|
|
Protection
|
Software Protection
|
l Data protection when power supply drop
|
|
l Off-line Testing Function
|
|
l Setting Protection Condition，Setting Parameter：
Low Voltage limit、Upper Voltage limit、Low Current limit、
Upper Current limit、Delay Time
|
|
Hardware Protection
|
Additional Anti-reverse Protection Model
|
|
Voltage and Current Testing Sample
|
4-wire connecting
|
|
Database
|
MySQL Database
|
|
The upper machine communication
|
RS485
|
|
Data Output
|
EXCEL、TXT
|
|
Per Unit Main Channels No.
|
8
|
