UV Anti-fogging coating PF-411

Strong fog resistance

Good adhesion

Colourless polymer functional material liquid



Description

UV Anti-fogging coating PF-411 is a colourless polymer functional material liquid. The main component of this product is UV hydrophilic resin, which hasgood adhesion on PC plastic board and excellent fog resistance. It has no stimulation to human body, strong adaptability and excellent construction performance.


Features

Strong fog resistance

Good adhesion


Qualification

Appearance :Transparent liquid

Density(g/cm2): 0.8-1.0

Coating thickness(μm): 5-8

Leveling temperature/time(℃ : 60℃

UV Curing Energy(J/cm*cm): 480-550


Application

PC sheets


Detection methods and performance indicators

Testing items

Test method

Result

Initial droplet angle

3-5 ml water, tested in 10 seconds

< 10 degrees

Scratch free

No fogging

No fogging

Dry film adhesion

Berg test

4B



Wet film adhesion

80 degrees steam fumigated nail scratch

Scratch free



Steam test

Place for 5 seconds at 10 cm above 80 C water vapor

No fogging



Steam test

Place it 10 cm above 80 C steam for 10 minutes, dry naturally, observe the appearance, and then do anti-fogging test.

No fogging


HOW TO USE

Before cleaning: wipe the PC board with absolute ethanol.

Spraying process: The sample can be uniformly sprayed on the sample plate with a disposable dropper, then placed vertically, and baked in a 60 degree oven for 3 minutes.

Curing process: UV curing, energy between 480-550 J/cm*cm.
