Vacuum suction truck Isuzu (14,000 Liters)
Applications:
Vacuum suction truck Isuzu (also called Hydraulic dump vacuum cleaner tanker, Sewage pump truck, Vacuum suction tanker, Vacuum truck, city vacuum loader) is is used for suction, transportation and dumping soil and mud from various sewer man-hole, water wells and sediment.
Vacuum Tank truck mady by Powerstar Trucks is necessary for city sanitation department, waste processing company, big factory..., it can help to clean the sewer pipe underground, clean the sludge in the river around city, it also can help big factory to clean the greasy dirt and waste water.More specification about the vacuum tank please kindly refer to following information.
Key Features:
---- ISUZU chassis, perfect performance
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure
---- Italy imported pump super powerful, efficient pump in and out
---- Strong, durable, perfect performance
Specifications:
|
Sewage vacuum truck Isuzu (8,000L)
|
|
General
|
Vehicle Brand
|
POWERSTAR
|
|
Chassis Brand
|
ISUZU
|
|
Overall Dimension
|
7620 * 2300 * 3100 mm
|
|
GVW / Kerb Weight
|
10,000kg / 4,580kg
|
|
Cab
|
Cab Capacity
|
3 persons allowed
|
|
Air Conditioner
|
Heating/cooling air conditioner
|
|
Engine
|
Fuel Type
|
Diesel
|
|
Engine Brand
|
ISUZU
|
|
Power
|
190 HP (139 KW)
|
|
Displacement
|
5200 ml
|
|
Emission Standard
|
Euro IV or V
|
|
Chassis
|
Drive Type
|
4X2, (left hand drive)
|
|
Transmission
|
6 speed levers with 1
reverse
|
|
Wheelbase/No. of axle
|
4175 mm / 8
|
|
Tire Specification
|
8.25-20
|
|
Tire Number
|
10 tires and 1 spare tire
|
|
Max Speed
|
95 km/h
|
|
Paint
|
Metallic paint
|
|
Superstructure
|
Tank Capacity
|
14,000 Liters
|
|
Tank shape
|
Ellipse
|
|
Material
|
Carbon steel, 4mm
|
|
Body Material
|
Weather resisting
steel
|
|
Vacuum pump
|
Italy / China famous brand
|
|
Control
|
Manual
|
|
Hose
|
Wire strengthened hose
|
|
All standard accessories: Warning
lights, music alarm, basic tool kit, English manual……
|
|
Optional
|
** Backup alarm can be equipped.
** Other vacuum pump can be equipped.
** Water jetting can be optional.
** Operation language can be English or Appointed language.
|
---- SGS, BV, CONTECNA, CE Qualified.
---- Local engineer training support.
---- 12 months FREE parts.
---- Factory genuine parts supply.
---- 7 days to worldwide by DHL.
| Operation Manual |
Chassis parts |
Maintenance Tools |
---- 15 years experiences Design & Export.
---- 100% customer made trucks.
---- Fast delivery assurance.
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
---- Maximize save your sea freight.
---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely
---- Quickly ship to worldwide.
---- Color and LOGO can be wished.
