4x2 350HP ISUZU VC46 Heavy duty Trucks Tractor Prime Mover
Isuzu Prime Mover Truck Tractor Unit
Isuzu Truck tractor unit is an articulated vehicle composed of a towing engine or tractor and a trailer that carries the freight. The tractor and trailer are detachable, that is, the tractor can be used to haul other trailers, or vice versa. According to connection type of tractor and trailer, there are full trailer and semi trailer. A full trailer is a trailer that is supported by front and rear axles and pulled by a drawbar. A semi trailer is a trailer that has no front axle and is supported by a road tractor.
Key further of 350HP Isuzu VC46 Prime Mover
1. Excellent Isuzu 6UZ1 Surging Power
2. Lightweight and High Strength Frame
3. Style of Great General
4. Working with Great Care
5. Cost-efficient and Worry-free Performance
Main specifications:
Model
|
PT4250UK46
|
Driving Type
|
4x2
|
Left hand drive
|
Weight
|
Kerb Weight (kg)
|
6450
|
Max. Fifth Wheel Payload (kg)
|
15000 kg
|
Max. Towed Mass (kg)
|
30000 kg
|
Overload Range of Gross Vehicle Weight (kg)
|
40000 @ complex road
|
Dimensions (mm)
|
Wheelbase
|
3450
|
Overall Dimension
|
5790x2490x3580
|
Front Overhang
|
1370
|
Rear Overhang
|
970
|
King Pin Diameter
|
90#
|
Min. Ground Clearance
|
285
|
Cab
|
All-steel-welded construction, 3 seats with 1 sleeper
|
Engine
|
Model:
|
6UZ1-TCG40
|
Cylinder in Line
|
6
|
Capacity
|
9839 ml
|
Type
|
Diesel, turbo charged inter-cooled
|
Max. Power:
|
257/2000 KW/RPM
|
Max. Torque
|
1422/140 N.m/RPM
|
Gearbox
|
12JS160TA 12-shift, mechanical type, 12 forward and 2 reverse with
|
Brakes
|
Type
|
2 independent pneumatic circuits, disc/drum
|
Parking
|
Mechanic with spring cylinder, rear
|
Emergency
|
Combined with parking brake
|
Engine
|
Decompression
|
ABS
|
Yes
|
Axles
|
Type
|
ISUZU exclusive high-performance axle
|
Loading
|
Front 9T
Rear 20T+20T
|
Tyre
|
11.00-20
|
Fuel tank
|
400 L
|
Color
|
White
|
Max Speed
|
105 km/h
|
