Volumetric piston water flow meter

Volumetric water meters are more accurate than speed meters. The velocity meter measurement error will have an error of ±2% depending on the fluid velocity, while the volumetric water meter error can be controlled to ±0.5% or lower.



Product parameters

Type: pure water meter;
Structure form: volumetric water meter
Accuracy: Class C
(4) Nominal diameter: 13 (mm)
Nominal pressure: 1 (MPa)
Working temperature: 45 ° C
The largest size: 99999
Minimum reading: 0.01.

Performance characteristics of volumetric water meters

Measurement level
Volumetric water meters have a high level of measurement and can generally reach Class C or Class D.

Pressure loss
The pressure loss of a volumetric water meter under overload flow does not exceed 0.1 MPa.

Pressure strength

The volumetric water meter can withstand the pressure test of water pressure 1.6MPa, continuous 15min, water pressure 2.0MPa, continuous 1min.


Media and installation requirements

The volumetric water meter has higher requirements on water quality than the rotor type water meter, and the wear is large. If there is impurity in the water flow, the main piston or the main plate will be blocked, the water supply will stop, and the water quality directly affects its service life. As the amount of wear and leakage increases, the metering performance of the volumetric water meter changes slowly.

Performance comparison

Compared with the rotary vane  type(single jet,multi jet ,woltman ) water meter, the volumetric water meter has the advantages of high metering level and good sensitivity, but requires high water quality, complicated structure, and difficulty in manufacturing and maintenance.volumetric water meter
