Specification (Can be revised base on customer's requirements)
|
Internal dimension(W*D*H)
|
1500*4000*2000mm
|
|
External dimension(W*D*H)
|
2200*4875*2350mm
|
|
Tested sample details
|
Max sample size: 1.2*1.2*1m (W*D*H)
Max sample weight <50kg
Number: two samples can be tested one time
|
|
Door size (W*H)
|
Double Door, 1500 * 2000mm
|
|
Temperature range
|
-40℃~100℃
|
|
Temperature Accuracy
|
±2℃
|
|
Humidity range
|
20~90%R.H.
|
|
Humidity accuracy
|
±5%R.H
|
|
Internal chamber material
|
Tempered glass + SUS304
|
|
External chamber material
|
Tempered glass+ SUS304
|
|
Controller
|
LCD touch screen, programmable control temperature and humidity
Can set different parameter for cyclic test
|
|
Insulation material
|
50mm high density rigid Polyurethane foam
|
|
Heater
|
Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
|
|
Compressor
|
France Tecumseh compressor
|
|
Lighting
|
Heat resistance
|
|
Temperature sensor
|
PT-100 dry and wet bulb sensor
|
|
Air conditioning channel
|
Air-conditioning box air supply
|
|
Testing hole
|
Diameter 50mm, for cable routing
|
|
Special configuration
|
Indoor axial fan strong exhaust (air exchange rate 5~10 times/H)
Formaldehyde, TVOC inlet valve
Cleanliness B + C level
|
|
Safety protection device
|
Protection for leakage
Over-temperature
Compressor overvoltage and overload
Heater short circuit
Water shortage
|
