Water based fluororesin non-stick mold coating PF-602

PF-602 is designed for metal mold coating. It has excellent non-stick performance, good heat resistant and abrasion resistant. It can be used for aluminum, steel and other metal mold coating.



Description

Water based fluororesin non-stick mold coating PF-602 is designed for metal mold coating. It has excellent non-stick performance, good heat resistant and abrasion resistant. It can be used for aluminum, steel and other metal mold coating.


Type

-Water based fluororesin


Key features

-PFOA free

-Excellent non-stick performance and heat resistant

-Excellent chemical resistance and abrasive resistance

-Excellent and lasting non-stick performance, easy to clean


Typical properties

Appearance:                                   Liquid (Customized color)

Solid content (%):                           33±1 (Primer)

                                                        35±1 (Top)

Viscosity (cp):                                  500~900 Primer

                                                        400~750 Top

Density (g/ml):                                 1.28 Primer/1.30 Top

pH:                                                   8-11(Primer and top)

Color of the film surface:                  Flat and smooth

Curing temperature (℃):                  380-420

Gloss (60° glossimeter):                  15-25

Film thickness (μm):                         20-35

Non-stick performance:                    >10 cycles (Fry eggs at 170±10℃)

Corrosion resistance:                       No blister (Boling 10% salt water for 24 hours)

Abrasion resistance 3KG/21cm2:     >4000 cycles

Hardness (ZHONGHUA pencil):       >F


Application

-Aluminum, steel and other metal mold coating


Storage and handling

-Available in 20 kg/ barrel or 30 kg/ barrel

-Store products in tightly closed original containers at 5-40℃

-Shelf life: 9 months from delivery date

-According to non-dangerous goods transport


Non-stick Coating Type

↓ ↓ ↓ Please click product model for more informations

Model Layer Thickness Curing temperature Non stick property Anti-corrosion Abrasion resistant
  Water based fluororesin non-stick coating
PF-600 2 25-40 380-400 A A A A A A A A A A A A
PF-601 2 25-35 380-400 A A A A A A A A A A A
PF-602 2 25-40 380-400 A A A A A A A A A A A A
PF-610 3 20-35 380-420 A A A A A A A A A A A A A
PF-611 3 20-35 380-420 A A A A A A A A A A A A A
PF-612 3 20-35 380-420 A A A A A A A A A A A A A
  Water based ceramic non-stick coating
C-104 1 30-45 280-300 A A A A A A A A A A A A A A
C-105 1 30-45 280-300 A A A A A A A A A A A A A A
C-106 2 34-50 280-300 A A A A A A A A A A A A A A
C-107 1 12-20 250-280 A A A A A A A A A A A A A A
C-108 2 34-50 280-300 A A A A A A A A A A A A A A
C-109 2 34-50 280-300 A A A A A A A A A A A A A A
  Silicone resin non-stick coating
S-200 1 15-20 280-300 A A A A A A A A A A A A A
S-201 1 15-20 280-300 A A A A A A A A A A A A A A
S-202 1 15-20 280-300 A A A A A A A A A A A A A
