Impedance:50 Ω
Frequency Range:DC - 4 GHz
VSWR: :DC - 2 GHz:2 GHz - 4 GHz
Spec requirement:1.40 max:1.50 max
Straight SMB (cable group 1):1.15 max:1.25 max
Right angle SMB (cable group 1):1.20 max:1.35 max
Straight SMB (cable group 4):1.10 max:1.15 max
Insertion Loss:Spec requirement: < .3 dB max from DC - 3GHz
Up to 1 GHz: < .1 dB
Up to 2 GHz: < .2 dB
Up to 4 GHz: < .3 dB
Insulation Resistance:1000 MΩ minimum
Center Contact Resistance:Center contact: < 20 mΩ
Outer contact: < 10 mΩ
Dielectric Withstanding Voltage:> 1,000 VRMS at sea level
Frequency Range:DC - 4 GHz
VSWR: :DC - 2 GHz:2 GHz - 4 GHz
Spec requirement:1.40 max:1.50 max
Straight SMB (cable group 1):1.15 max:1.25 max
Right angle SMB (cable group 1):1.20 max:1.35 max
Straight SMB (cable group 4):1.10 max:1.15 max
Insertion Loss:Spec requirement: < .3 dB max from DC - 3GHz
Up to 1 GHz: < .1 dB
Up to 2 GHz: < .2 dB
Up to 4 GHz: < .3 dB
Insulation Resistance:1000 MΩ minimum
Center Contact Resistance:Center contact: < 20 mΩ
Outer contact: < 10 mΩ
Dielectric Withstanding Voltage:> 1,000 VRMS at sea level
