WiFi access points IEEE 802.11b/g WLAN Systems antenna

9 dBi
SMA
Φ14×380(mm) 2400-2483MHz;12dbi;RPSMA;elbow right angle male;black version



Frequency;2400-2483MHz
Bandwidth;83MHz
VSWR;≤1.8
Gain;9dBi
Polarization Type;Vertical
Rated Power;50w
Input Impedance;50Ω


Product Tags antenna terminal          wlan terminal antenna          rubber terminal antenna          terminal pcb antenna          2.4ghz terminal antenna          4g terminal antenna          pcb terminal antenna          ts9 termination antenna          ts9 termination antennas
