1) Led Module
|
Module Size(W*H)
|
192*192mm
|
Pixel Configeration
|
1R1G1B
|
|
Pixel Pitch
|
6mm
|
Resolution(W*H)
|
32*32dots
|
|
Pixel Density
|
27,777dots/m2
|
Driving Method
|
1/8 scanning
|
2) Led cabinet
|
Cabinet Size(W*H)
|
960*960mm or customized
|
Module Qty
|
25pcs
|
|
Cabinet Resolution(W*H)
|
160dots*160dots
|
Cabinet Pixel
|
25600
|
|
Weight
|
about 35kg/pc
|
Area
|
0.9216(m2)
|
|
Average Power Consumption
|
240W/m2
|
Max Consumption
|
600W/m2
|
3) Led Video Wall Technical Parameter
|
Operating Humility
|
10%~90%RH
|
|
Oprating Temprature
|
-20℃~+50℃
|
|
Optimal Viewing Distance
|
10m-60m
|
|
Display Color
|
1,070,000,000
|
|
Gray Scale
|
65536grade
|
|
Bightness control
|
256grade
|
|
Frame Frequency
|
60Hz
|
|
Refresh speed
|
>300HZ
|
|
Power supply
|
220V/50HZ
|
|
MTBF
|
≥10,000hours
|
|
Life span(50% brightness)
|
≥100,000hours
|
|
Control Mode
|
Synchronization with PC
|
|
Input Signal Format
|
VGA,DVI,RGBHV,PbPr(HDTV),Composite,S-video,TV
|
|
Operating System
|
WINDOWS(98,2000,XP,Vista)
|
