This technical note identifies key differences between the 5136-DNP/DN interface cards and SST DeviceNet Generation III (SST-DN3) interface cards, from both a software and hardware standpoint. This document does not replace the relevant Hardware and Firmware Reference Guides, nor is it intended as a developer’s reference. Its goal is to describe new features and changes to product behavior.
Storage temp: -40°C to +85°C
Operating temp: 0°C to 55°C
Humidity: 5% to 95% non-condensing
Typical Current Draw 575mA – PCU-1 1.03A – PCU-2
Voltage Requirements 5 volt
Size Standard half-length, 32-bit, 33MHz, 5V PCI card
Addressing (memory) 256KB available per channel (I/O) 8-byte range available per channel (memory) 128 bytes for PCI configuration, per card
