General
|
|
|
Device Type
|
Switch - 24 ports -
managed
|
|
Enclosure Type
|
Rack-mountable 1U
|
|
Subtype
|
Fast Ethernet
|
|
Ports
|
24 x 10/100 + 2 x
10/100/1000
|
|
Performance
|
Switching capacity:
32 Gbps ¦ Forwarding performance (64-byte packet size): 6.5 Mpps
|
|
MAC Address
Table Size
|
8K entries
|
|
Remote
Management Protocol
|
SNMP
1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP,
HTTPS, TFTP, SSH
|
|
Encryption
Algorithm
|
SSL
|
|
Authentication
Method
|
Secure Shell (SSH),
RADIUS, TACACS+
|
|
Features
|
Layer
2 switching, auto-sensing per device, dynamic IP address assignment,
auto-negotiation, BOOTP support, ARP support, load balancing, VLAN support,
auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ
support, Broadcast Storm Control, IPv6 support, Multicast Storm Control,
Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple
Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking
Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access
Control List (ACL) support, Quality of Service (QoS), Link Aggregation
Control Protocol (LACP), Port Security, MAC Address Notification, Remote
Switch Port Analyzer (RSPAN)
|
|
Compliant
Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE
802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE
802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
|
|
RAM
|
64 MB
|
|
Flash Memory
|
32 MB flash
|
|
Status
Indicators
|
Port transmission
speed, port duplex mode, power, link OK, system, link/activity
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
24 x 100Base-TX RJ-45
¦ 2 x 1000Base-T RJ-45
|
|
Power
|
|
|
Power Device
|
Internal power supply
|
|
Voltage
Required
|
AC 120/230 V (50/60
Hz)
|
|
Power
Consumption Operational
|
28 Watt
|
|
Miscellaneous
|
|
|
Rack Mounting
Kit
|
Optional
|
|
MTBF
|
407,707 hours
|
|
Compliant
Standards
|
TUV
GS, CISPR 22 Class A, GOST, BSMI CNS 13438 Class A, CISPR 24, NOM, VCCI Class
A ITE, EN55024, CB, EMC, MIC, IEC 60950-1, EN 60950-1, UL 60950-1 Second
Edition, RoHS, CSA C22.2 No. 60950-1, FCC Part 15 B Class A
|
|
Software /
System Requirements
|
|
|
Software
Included
|
Cisco LAN Base
software
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5 in
|
|
Depth
|
9.3 in
|
|
Height
|
1.7 in
|
|
Weight
|
8 lbs
|
|
Manufacturer
Warranty
|
|
|
Service &
Support
|
Limited warranty -
lifetime
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
23 °F
|
|
Max Operating
Temperature
|
104 °F
|
|
Humidity Range
Operating
|
10 - 95%
(non-condensing)
|
|
Min Storage
Temperature
|
-13 °F
|
|
Max Storage
Temperature
|
158 °F
|
|
Humidity Range
Storage
|
10 - 95%
(non-condensing)
|
|
Model No
|
WS-C2960-24TT-L
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
