WS-C2960X-24PSQ-L Overview
Cisco catalyst 2960X-24PSQ-L LAN Base standalone Layer 2 switch offers twenty-four 10/10/1000 Ethernet Gigabit ports and two 1G SFP, and two
Copper 10/100/1000 uplink interfaces. The industry standard IEEE802.3at PoE+ provides up to 110W PoE power which can powers up to 8 ports
of POE(first eight ports only) with 12.95W per port or 7 ports of POE with 15.4W per port or 3 ports of POE with 30W per port.
WS-C2960X-24PSQ-L Specification
|
Brand
|
Cisco
|
|
Part
number
|
WS-C2960X-24PSQ-L
|
|
Product
Description
|
Catalyst 2960-X 24 GigE PoE 110W. 2xSFP +
2x1GBT. LAN Base
|
|
Enclosure
Type
|
Rack-mountable - 1U
|
|
Feature
Set
|
LAN Base
|
|
Uplink
Interfaces
|
2 x 1G SFP + 2 x 10/100/1000BT
|
|
Ports
|
24 x 10/100/1000 Ethernet
Gigabit ports (8 PoE)
|
|
Available
PoE Power
|
Available PoE Power
|
|
Maximum
stacking number
|
Not Supported
|
|
Stack
bandwidth
|
Not Supported
|
|
Forwarding
Performance
|
71.4Mpps
|
|
Switching
Bandwidth
|
216Gbps
|
|
RAM
|
512 MB
|
|
Flash
Memory
|
128 MB
|
|
Console
ports
|
Console ports
|
|
Dimensions
|
44.5 cm x 28 cm x 4.45 cm
|
|
Weight
|
5.8 Kg
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
