Capacity
|
|
|
Type
|
Virtual interfaces (VLANs)
|
|
Value
|
4094
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5 in
|
|
Depth
|
19.1 in
|
|
Height
|
1.7 in
|
|
Weight
|
17.2 lbs
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
23 °F
|
|
Max Operating Temperature
|
113 °F
|
|
Humidity Range Operating
|
5 - 96% (non-condensing)
|
|
Min Storage Temperature
|
-40 °F
|
|
Max Storage Temperature
|
158 °F
|
|
Flash Memory
|
|
|
Installed Size
|
2 GB
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco Systems
|
|
Packaged Quantity
|
1
|
|
Product Line
|
Cisco Catalyst
|
|
Model
|
3650-48FS-S
|
|
Brand
|
Cisco
|
|
Interface
Provided
|
|
|
Qty
|
48
|
|
Type
|
Management (mini-USB)
|
|
Connector Type
|
Type B
|
|
Comments
|
Management
|
|
PoE Power
|
30 W
|
|
Miscellaneous
|
|
|
Rack Mounting Kit
|
Included
|
|
Compliant Standards
|
BSMI CNS 13438 Class A, CISPR 22
Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second
Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A,
GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, KN22 Class
A, KN24, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class A
|
|
Authentication Method
|
RADIUS, Secure Shell (SSH),
TACACS+
|
|
MTBF
|
383,760 hours
|
|
Height (Rack Units)
|
1
|
|
Color Category
|
Black
|
|
Networking
|
|
|
Type
|
Switch
|
|
Connectivity Technology
|
Wired
|
|
Remote Management Protocol
|
CLI, RMON 1, RMON 2, RMON 3,
RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
|
|
Compliant Standards
|
IEEE 802.1ab (LLDP), IEEE
802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE
802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE
802.3u, IEEE 802.3x, IEEE 802.3z
|
|
Status Indicators
|
Active, PoE, Port duplex mode,
Port transmission speed, Status, System
|
|
Ports Qty
|
48
|
|
Features
|
Access Control List (ACL)
support, ARP support, DHCP snooping, Dynamic ARP Inspection (DAI), EIGRP Stub
Routing, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping,
Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree
Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of
Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+),
Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer
(RSPAN), Trunking, Uni-Directional Link Detection (UDLD), VLAN support
|
|
Routing Protocol
|
EIGRP, RIP-1, RIP-2, RIPng,
Static IP routing
|
|
MAC Address Table Size
|
32000 entries
|
|
Stackable
|
Stackable
|
|
Subcategory
|
Network hubs and switches
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
Advanced Switching
|
Layer 3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Desktop, Rack-mountable
|
|
Jumbo Frame Support
|
9198 bytes
|
|
Subtype
|
Gigabit Ethernet
|
|
PoE Budget
|
775 W
|
