Technical
Specifications
|
|
|
General
|
|
|
Device Type
|
Switch
- 8 ports - L3 - managed
|
|
Enclosure
Type
|
Rack-mountable
2U
|
|
Subtype
|
10
Gigabit Ethernet
|
|
Ports
|
8
x X2
|
|
MAC Address
Table Size
|
55K
entries
|
|
Routing
Protocol
|
RIP-1,
RIP-2, EIGRP, static IP routing
|
|
Remote
Management Protocol
|
SNMP
1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3
|
|
Features
|
Layer
3 switching, layer 2 switching, BOOTP support, VLAN support, IGMP snooping,
Broadcast Storm Control, IPv6 support, Dynamic Trunking Protocol (DTP)
support, Trivial File Transfer Protocol (TFTP) support, Quality of Service
(QoS), Jumbo Frames support
|
|
Compliant
Standards
|
IEEE
802.1Q, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP)
|
|
Processor
|
1:
1.3 GHz
|
|
RAM
|
512
MB
|
|
Flash Memory
|
128
MB flash
|
|
Status
Indicators
|
Port
status, power, system
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
2
x USB ¦ 1 x RJ-45 management ¦ 1 x console RJ-45 ¦ 8 x X2
|
|
Expansion
Slots
|
2
(total) / 2 (free) x expansion slot ¦ 1 (total) / 1 (free) x CompactFlash
Card
|
|
Power
|
|
|
Power Device
|
Internal
power supply - hot-plug
|
|
Installed Qty
|
0
(installed) / 2 (max)
|
|
Power
Redundancy
|
Optional
|
|
Power
Redundancy Scheme
|
1+1
(with optional power supply)
|
|
Miscellaneous
|
|
|
Compliant
Standards
|
NEBS
level 3, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, EN50082,
EN55022, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A,
UL 60950, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A,
FCC Part 15 A
|
|
Dimensions
& Weight
|
|
|
Width
|
17.2
in
|
|
Depth
|
17.9
in
|
|
Height
|
3.5
in
|
|
Weight
|
24.91
lbs
|
|
Manufacturer
Warranty
|
|
|
Service &
Support
|
Limited
warranty - 1 year
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
32
°F
|
|
Max Operating
Temperature
|
104
°F
|
|
Humidity
Range Operating
|
10
- 90%
|
