WS-C6503-E Overview
A three-slot chassis in a compact size, the Cisco Catalyst 6503 is ideally suited for multi-Gbps secure data centers, remote access, e-commerce, and converged network solutions.Using the same supervisor modules and line cards from the Cisco Catalyst 6500 Series, the Cisco Catalyst 6503 offers maximum investment protection and broadens the deployment options of the Cisco Catalyst 6500 in the wiring closet, distribution, core, data center, and WAN edge.
WS-C6503-E Specification
|
Product Code
|
WS-C6503-E
|
|
Number of Slots
|
3
|
|
Supervisor Compatibility
|
Cisco Catalyst 6500 Series Supervisor Engine 32
Cisco Catalyst 6500 Series Supervisor Engine 720-3B
Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3C
Cisco Catalyst 6500 Series Supervisor Engine 720-10G-3CXL
Cisco Catalyst 6500 Series Supervisor Engine 720-3BXL
Cisco Catalyst 6500 Series Supervisor Engine 2T
|
|
Power Supply Compatibility
|
AC: 1400W, 950W*
|
|
* Indicates EoS Power Supply
|
DC:
950W*
|
|
Module Compatibility
|
All modules based on the software release in the
system
|
|
With Supervisor Engine 32
|
12.2(18)SXF
|
|
With Supervisor Engine 720
|
2.2(14)SX
|
|
With Supervisor Engine 720-10 GE
|
12.2(33)SXH
|
|
With Supervisor Engine 2T-10 GE
|
15.0(1)SY
|
Reliability and
Availability Calculated
Mean Time Between Failure (MTBF)
|
860868
|
|
Dimension
|
7 x 17.37 x 21.75 in (17.8 x 44.1 x 55.2 cm)
|
|
Rack Units (RU)
|
4
|
|
Weight
|
Chassis Only (lbs): 33
Fully Configured (lbs): 85.4
|
|
Lead time
|
2-3
business days
|
|
Shipment
|
DHL,
Fedex, Aramex, EMS or per request
|
