WS-CAC-6000W Overview
If you're in need of a power supply, the Cisco WS-CAC-6000W may be exactly what you need. A hot-plug, plug-in AC Power module, the Catalyst 6500 6000W is compatible with all Cisco Catalyst 6500 Series Switches. The product, as its name suggests, provides 6000 Watts of output power if both inputs are 220 VAC and 2900W if both inputs are active, but at least one of the inputs is at 110 VAC or a single input is active and at 220 VAC. While many AC power modules produce 2500 - 4000 watts of AC power, the WS-CAC-6000W provides a higher wattage power supply which will be able to support future PoE devices. In short, it's a good investment whether or not upgrading to a higher-performance system is in your future plans. As a replacement model the recommended (and minimum) CatOS is 8.4(1) and recommended (and minimum) IOS (12.2S train) is 12.2(18)SXD.
WS-CAC-6000W Specification
|
put-voltage range and
frequency
|
100-240 VAC, 47-63 Hz
|
|
Input current (each
input)
|
16A
|
|
Input-frequency range,
output power
|
6000W if both inputs
are 220 VAC
|
|
|
2900W if both inputs
are active but at least 1 is at 110 VAC or a single input is active and at
220 VAC
|
|
Output holdup time
|
20 ms minimum
|
|
Power-supply input
receptacles
|
IEC 320-C19
|
|
Power cord rating
|
16A
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
