CiscoCisco WS-X45-SUP8L-E Catalyst 4500 E-Series Supervisor 8L-E overview
WS-X45-SUP8L-E= is Cisco Catalyst 4500E Series Supervisor Engine 8L-E, 560 Gbps. It is supported in Cisco Catalyst 4500 E-Series chassis.
Cisco leadership in borderless networks is extended with important features: Cisco TrustSec®, Cisco MultiGig, Flexible NetFlow, Cisco EnergyWise®, Cisco UPoE, and many other feature enhancements offered by the Cisco Catalyst 4500E Supervisor Engine 8L-E. Backward and forward compatibility with most existing Cisco Catalyst 4500E line cards and power supplies helps assure deeper customer satisfaction with an industry-leading investment protection architecture. The Cisco Catalyst Supervisor Engine 8L-E is supported in Cisco Catalyst 4500 E-Series chassis.
The Supervisor Engine 8L-E offers important innovations, including:
-
560 Gbps total capacity with 4x SFP/SFP+ uplinks and a Quad Core, 1.8Ghz CPU
-
Cisco Universal Power over Ethernet (UPOE) for unprecedented convergence to IP network infrastructure
-
Campus ready for connectivity to next-generation NBASE-T™ compatible endpoints such as 802.11ac Wave2 multigigabit access points, multigigabit switches, network interface cards (NICs), and adapters
-
Application visibility through Flexible NetFlow.
-
Virtual Switching System (VSS) for operational simplicity and resiliency
-
Cisco IOS® XE Software, which provides the ability to host third-party applications
-
Energy efficiency with support for 802.3az Energy-Efficient Ethernet (EEE)-capable line cards
-
Industry-leading resiliency through In-Service Software Upgrade (ISSU)
-
First and only modular switch with 8 bidirectional line-rate Switched Port Analyzer/Remote SPAN (SPAN/RSPAN) sessions
Specification
Product Number
|
WS-X45-SUP8L-E
|
uplinks
|
4x SFP/SFP+
|
Ports
|
4 nonblocking 10 Gigabit Ethernet uplinks (SFP+) or 4 nonblocking 1 Gigabit Ethernet uplinks (SFP)
|
console and Management Port
|
10/100/1000 RJ-45
|
MAC addresses
|
55,000
|
CPU
|
Quad core; 1.8 GHz
|
Centralized switching capacity
|
560 Gbps
|
Bandwidth per slot
|
48 Gbps
|
Throughput
|
·225 Mpps for IPv4
·110 Mpps for IPv6
·225 Mpps for L2 Bridging
|
Boot flash
|
2G
|
Synchronous Dynamic RAM (SDRAM)
|
4 GB
|
Active supervisor power
|
240W
|
Standby supervisor power
|
120W
|
Number of routes
|
64K for IPv4, 32K for IPv6
|
weight
|
6.04 lb (2.94 kg)
|
