WS-X4648-RJ45V+E Catalyst 4500 E-Series 48-Port PoE+ Ready 10/100/1000(RJ45)
Cisco catalyst WS-X4648-RJ45V+E line-card is designed with 48 POE ports which functions up to 30W of inline power per port on 24 ports simultaneously or 15W of inline power per port on 48 ports simultaneously.
WS-X4648-RJ45V+E Overview
Cisco catalyst WS-X4648-RJ45V+E line-card is designed with 48 POE ports which functions up to 30W of inline power per port on 24 ports simultaneously or 15W of inline power per port on 48 ports simultaneously. WS-X4648-RJ45V+E delivers high-performance and secures user experience with superior backward and forward compatibility to process large file transfers and network backups for campus and branch applications. This WS-X4648-RJ45V+E is similar with the WS-X4648-RJ45V+E=. The WS-X4648-RJ45V+E= is a spare one.
WS-X4648-RJ45V+E Specification
| Brand | Cisco |
| Part number | WS-X4648-RJ45V+E |
| Product Description | Catalyst 4500 E-Series 48-Port PoE+ Ready 10/100/1000(RJ45) |
| Line-Card Type | Cisco catalyst 4500 E-series line card |
| Chassis Support | 4503-E/4506-E/4507R+E/4510R+E/4507R-E/4510R-E |
| Supervisor support | 7L-E/7-E/8-E |
| switching capacity | Up to 24 Gbps |
| ports | 48 * 10/100/1000 Gigabit Ethernet POE+ ports |
| module | 10/100/1000 module (RJ-45) |
| Cisco IOS XE | Cisco IOS Software Release 12.2(40)SG or later |
| Max Rated Power (W) | 89 |
| Rated MTBF (Hours) | 280365 |
| Bandwidth | Bandwidth is allocated across eight 6-port groups, providing 3 Gbps per port group (2:1) |
| Enterprise and commercial | designed to power next-generation IP phones, wireless base stations, video cameras, and other PoE devices |
| inline power | Capable of up to 30 W of inline power per port on up to 24 ports simultaneously or 15W of inline power per port on up to 48 ports simultaneously |
| flow control | IEEE 802.3af/at and Cisco prestandard PoE, IEEE 802.3x flow control |
| L2-4 Jumbo Frame support | up to 9216 bytes |
| Warranty | One year |
| Lead time | 2-3 business days |
| Shipment | DHL, Fedex, Aramex, EMS or per request |
