WS-X6824-SFP-2T Overview
WS-X6824-SFP-2T is integrated with 24-port SFP fiber Gigabit Ethernet interface module with WS-F6K-DFC4-E daughter card for 6500 E-series with supervisor 2T only. Equipped with WS-F6K-DFC4-E daughter card, WS-X6824-SFP-2T ensures to deliver optimal performance up to a sustained 60Mpps for layer 2, IPV4 and MPLS forwarding, and makes this module ideally suited for high performance enterprise, Service provider distribution, core layer, data-center and Metro Ethernet applications. The 24-port module has one 20G fabric connection while the other new modules have two 20G fabric connections (for 40G total bandwidth).
WS-X6824-SFP-2T Specification
|
Brand
|
Cisco
|
|
product
|
WS-X6848-SFP-2T
|
|
Transceiver
Type
|
Small Form-factor
Pluggable (SFP)
|
|
Ports/Interface/Connectors
|
48 port; 1000BASE-SX,
LX/LH, -ZX, -T;1000BASE-CWDM; LC connecter
|
|
Port
Density/Chassis Model
|
528 ports/6513E 384
ports/6509E
|
|
Maximum Frame
Size
|
Up to 9216
bytes/frame
|
|
Queues per
Port (Tx = Transmit, Rx = Receive)
|
Tx-1p3q8t; Rx-2q8t
|
|
Scheduler
|
DWRR
|
|
Buffer Size
per Port
|
Rx-166KB Tx-1.17MB
|
|
Onboard Memory
|
1GB Default
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
