WS-X6848-SFP-2TXL Overview
Cisco Catalyst 6500 Ethernet Module - WS-X6848-SFP-2TXL Catalyst 6500 48-port GigE Mod: fabric-enabled with DFC4XL for Cisco 6500
WS-X6848-SFP-2TXL Specification
|
Standard protocols
|
IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ak, IEEE 802.3aq, and IEEE 802.3an |
| Physical specifications | Occupies one slot in the Cisco Catalyst 6500 E-Series chassis |
| Dimensions (H x W x D): 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm) | |
| Weight: | |
| WS-X6816-10G-2T & 2TXL, WS-X6816-10T-2T & 2TXL: 13.6 pounds excluding X2 components; ¼ pound for each X2 | |
| Environmental conditions | Operating temperature: |
| Agency-certified for operation: 32 to 104°F (0 to 40°C) | |
| Design and tested for operation 32 to 130°F (0 to 55°C) | |
| Storage temperature: -40 to 167°F (-40 to 75°C) | |
| Relative humidity: 10 to 90 percent, noncondensing | |
| Operating altitude: | |
| Agency-certified for operation: -500 to 6500 ft (-150 to 2000m) | |
| Designed and tested for operation -500 to 10000 ft (-150 to 3000m) | |
| Regulatory compliance | 6800 Series 10 Gigabit Ethernet Copper module, when installed in a system, comply with the following EMC and safety standards: |
| EMC Standards: | |
| FCC Part 15 (CFR 47) Class A | |
| ICES-003 Class A | |
| VCCI Class A | |
| EN55022 Class A | |
| EN55024 | |
| CISPR24 | |
| CISPR 22 Class A | |
| AS/NZS CISPR 22 Class A | |
| ETS 300 386 | |
| KN 22 Class A | |
| EN 50082-1 | |
| EN61000-3-2 | |
| EN61000-3-3 | |
| EN61000-6-1 | |
| CNS13438 Class A | |
| KN6100 -4 Series | |
| Safety Standards: | |
| UL 60950-1 | |
| CAN/CSA C22.2 No. 60950 | |
| EN 60950-1 | |
| IEC 60950-1 | |
| AS/NZS 60950-1 | |
| IEC 60825 Class 1 | |
| EN 60825 Class 1 | |
| 21CFR 1040 | |
| NEBS criteria levels | SR-3580 Issue 3, June 2007 (GR-63-CORE, issue 3, and GR-1089-CORE, issue 4) |
| ETSI | ETS 300 019-2-1, Class 1.1 Storage |
| ETS 300 019-2-2, Class 2.1 and 2.2 Transportation | |
| ETS 300 019-2-3, Class 3.1E Stationary Use | |
| Network management | ETHERLIKE-MIB (RFC 1643) |
| IF-MIB (RFC 1573) | |
| Bridge MIB (RFC 1493) | |
| CISCO-STACK-MIB | |
| CISCO-VTP-MIB | |
| CISCO-CDP-MIB | |
| RMON MIB (RFC 1757) | |
| CISCO-PAGP-MIB | |
| CISCO-STP-EXTENSIONS-MIB | |
| CISCO-VLAN-BRIDGE-MIB | |
| CISCO-VLAN-MEMBERSHIP-MIB | |
| ENTITY-MIB (RFC 2037) | |
| HC-RMON | |
| RFC1213-MIB (MIB-II) | |
| SMON-MIB | |
| Power requirements | WS-X6816-10G-2T: 488.5 Watts |
| WS-X6816-10G-2TXL: 503.5 Watts | |
| WS-X6816-10T-2T: 514.96 Watts | |
| WS-X6816-10T-2TXL: 529.96 Watts | |
| Indicators | Status: green (operational), red (faulty), and orange (module booting) |
|
Link: green (port enabled and connected),
orange (port disabled), and off (port enabled and not connected)
|
