X67BC4321.L12-10 B&R X67 System Bus Controller

X67 bus controller, 1 CANopen interface, X2X Link power supply 15 W, 16 digital channels configurable as inputs or outputs, 24 VDC, 0.5 A, configurable input filter, 2 event counters 50 kHz, CAN bus galvanically isolated M12 connectors, high-density module.

HS CODE : 8538909200



Fieldbus: CANopen

16 digital channels, configurable as inputs or outputs

Auto-configuration of I/O modules

Easy I/O configuration using Automation Studio V4.3 or later

Constant response times even with large amounts of data (max. 32 Rx and 32 Tx PDOs)

Configurable I/O cycle (0.5 to 4 ms)

Possible to configure the transfer rate or have it detected automatically

Heartbeat consumer and producer, emergency producer

2x SDO server, NMT slave

Simple bootup (autostart)

Controller Area Network (CAN) is widespread in automation technology. CAN topology is based on a line structure and uses twisted wire pairs for data transfer. CANopen is a higher-layer protocol based on CAN. The standardized protocol offers very flexible configuration options.

This bus controller makes it possible to connect up to 253 X2X Link I/O modules to CANopen. A transition between IP20 and IP67 protection is possible by directly connecting X20, X67 or XV modules to one another at distances of up to 100 m each across control cabinet boundaries as required. All CANopen operating modes such as synchronous, event and polling are supported as well as PDO linking, life/node guarding, heartbeat, emergency objects and much more.
