Specifications
| Primary brand |
Yaskawa |
| Main function |
Variable Speed/Frequency Drive (VSD/VFD) / Inverter |
| Product series / family name |
V1000 series |
| Network frequency |
(output) 0.01-400 Hz
(input) 50/60 Hz |
| Functions |
Versatile Variable Speed/Frequency Drive (VSD/VFD) / Inverter - USA region
Speed search
Overtorque detection
Torque limit
17-step speed
Acceleration/Deceleration time switch
S-curve accel/decel
3-wire sequence
Auto-tuning
Dwell
Cooling fan on/off switch
Slip compensation
Torque compensation
Frequency jump
Upper/lower limits for frequency reference
DC injection braking at start and stop
Overexcitation braking
High slip braking
PID control
Energy saving control
Fault restart
Application presets |
| Supply voltage (AC) |
380Vac-480Vac (400Vac / 415Vac / 440Vac) |
| Display |
LED 5-digit display |
| Type of network |
3-phase input (3P) |
| Rated current |
4.1A (Normal duty)
3.4A (heavy duty)
120% / 60s (Normal duty) or 150% / 60s (heavy duty) overload current rating |
| Rated active power (kW) |
1.5kW (Normal duty)
0.75kW (heavy duty) |
| Rated power (HP) |
2HP (Normal duty)
2HP (Heavy-duty) |
| Protection functions |
Motor overheat
Overcurrent
Overload
Overvoltage
Undervoltage
Momentary power loss ride-thru
Overheat
Ground fault |
| Protection settings |
(Overcurrent) output current exceeds 200% of heavy duty rating
(Overload) 120% of rated output current; normal duty
(Overload) 150% of rated output current; heavy duty |
| Communication protocol |
RS-422
RS-485 |
| Mounting mode |
Wall mounting |
| Digital inputs |
1 x digital input (24Vdc; Sink/Source) (S1 - Forward / Stop)
1 x digital input (24Vdc; Sink/Source) (S2 - Reverse / Stop)
1 x digital input (24Vdc; Sink/Source) (S3 - External fault)
1 x digital input (24Vdc; Sink/Source) (S4 - Fault reset)
1 x digital input (24Vdc; Sink/Source) (S5 - Multi-step speed 1)
1 x digital input (24Vdc; Sink/Source) (S6 - Multi-step speed 2)
1 x digital input (pulse / 32kHz)
1 x digital input (STO) |
| Digital outputs |
1 x digital output (SPDT Single Pole Double Throw contact type) (MA-MB-MC; MC-MB closed means fault)
1 x digital input (Pulse train output; PTO) |
| Analog inputs |
1 x analog input (0-10Vdc) (Analog input 1)
1 x analog input (0-10Vdc) (Analog input 2) |
| Analog outputs |
1 x analog output (2mA / 0-10Vdc) (AM - Monitor output) |
| Degree of protection |
IP20
NEMA 1 |
| Net Height (mm) |
149.5 mm |
| Net Width (mm) |
108 mm |
| Net Depth (mm) |
137.5 mm |
| Ambient air temperature for storage |
-20...+60 °C |
| Technology used in component |
Standard heatsink fins |
| Rated apparent power (S) |
3.1kVA (Normal duty)
2.6kVA (heavy duty) |
| Application type |
Conveyors
Packagings
Fans
Pumps
Foods and beverages
Industrial washers
Compressors |
| Order code / Manufacturer SKU |
CIMRVU4A0004FAA |
