Removing the Motion Module while power is supplied to these device may damage the Motion Module or cause malfunction of the GL120 and GL130.
Use the following procedures to remove the Motion Module from the Mounting Base.
1) Turn OFF the power to the control power of Servo Amp, and power supply for external I/O device.
2) Turn OFF the power supply to the Power Supply Module on rack having the Motion Module mounted.
3) Remove all cables connected to the Motion Module.
4) Remove the Motion Module from the Mounting Base.
a) Loosen the Module mounting screw on the Module.
b) Rotate the Module until it disconnects from the Mounting Base.
c) Remove the Module from the Module hook on the Mounting Base.
