Model
|
Yokogawa S9562FA
|
|
Function
|
ESB Bus Node Unit
|
|
Supported Network
|
ESB Bus (Yokogawa Proprietary Bus)
|
|
Communication Speed
|
1.5 Mbps
|
|
Input Voltage
|
24 VDC
|
|
Power Consumption
|
4 W (max)
|
|
Operating Temperature
|
0°C to +50°C
|
|
Storage Temperature
|
-20°C to +70°C
|
|
Relative Humidity
|
5% to 95% (non-condensing)
|
|
Dimensions
|
150 mm x 50 mm x 100 mm
|
|
Weight
|
0.5 kg
|
|
Mounting
|
DIN Rail or Panel Mount
|
|
Isolation Voltage
|
500 V (Bus to Power)
|
|
Protection Features
|
Overvoltage, Short Circuit Protection
|
|
LED Indicators
|
Power, Communication Status, Error Status
|
Contact Information!
Discuss pricing and delivery time with a sales representative
sales7@amikon.cn
86-18965423501
86-18965423501
AMKPLC
The Yokogawa S9562FA ESB Bus Node Unit is a critical interface module designed to manage communication between Yokogawa's Enhanced Serial Bus (ESB) network and field devices.
It allows controllers within distributed control systems (DCS) to interact with various field instruments and I/O modules, ensuring smooth data exchange and process control in industrial environments.
The S9562FA is optimized for high-speed and reliable communication, enabling scalable and flexible system architectures in industries like oil and gas, power generation, chemical processing, and manufacturing.
