ZTE ETGH Service Board
Product Description
ZTE ETGH Service Board Product Features
formation/disbandment of personnel
interaction between the ONU and the OLT using the Multipoint Exchange Control Protocol (MPCP)，Organization of a MAC port for broadcasting a single copy (SCB)
dynamic bandwidth allocation (DBA)
automatic detection, registration and remote testing of subscriber devices (ONU); encryption data using a triple swirl (AES-128)
direct error correction (FEC)
administration and maintenance during operation
Alarm support between OLT and ONU
statistics generation (the number of received/transmitted packets, detected errors
|
Brand
|
ZTE
|
|
Model
|
ETGH
|
|
GPON Port
|
16-EPON Port
|
|
Operating Wavelength
|
Tx: 1490 nm, Rx: 1310 nm
|
|
Encapsulation Type
|
PX 20 PX 20+ PX 20++
|
|
Port Rate
|
Tx: 2.488 Gbit/s, Rx: 1.244 Gbit/s
|
|
Optical Connector Type
|
SC/PC
|
|
Optical Fiber Type
|
Single-mode
|
|
Reach
|
20.00 km
|
|
Extinction Ratio
|
8.2 dB
|
|
Weight
|
1.5KG
|
|
Dimensions (W x D x H)
|
22.86 mm x 237.00 mm x 395.40 mm
|
Product Details
Our Advantages
We have ZTE ETGH for sale, including refurbished and new ones, and the price is usually 90% lower than the original supplier's price. Our super fast turnaround time and high-quality inventory all over the world mean that we can accurately deliver the products replaced on the same day to the place where they are needed, and minimize network downtime.
ZTE ETGH, like all our hardware, takes comprehensive warranty as the standard. Whether you need new products or renovated products, we only purchase green market equipment of the highest quality and environmental protection. All these are provided at the best possible price, and a large amount of cost-effectiveness will be directly passed on to you.
ZTE ETGH represents only one product in our world-class hardware portfolio. The portfolio includes very well-known industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel, Lucent, etc. We have a lot of inventory, thank you very much for sharing with customers.
